PRE ENGINEERED BUILDING SYSTEM
Pre Engineered Building consist of different steel-structural-members:
Purlins | Eave Struts | Side Runners | Fascia Channels | Doorposts | Window Posts | Rafters Stays | Column Stays | Base Angles Cold-formed "Z" and "C" shaped secondary structural members are Cold Roll Formed Light Gauge, which is made as per the design requirement and consists of: Roof Purlin | Eave Struts | Well Girts
The sheets and panels provided by us are of Galvanized/Galume aluminium/Stainless steel, Cold Rolled Low Carbon Steel Coils. They are of Two Coats, two Back Colour Coating Line of RMP/SDP/PU/SMP/PVDF/Plastisol Paint, solvent & Water Base PU & Polyester Guard Film.
HERE’S WHY CHOOSE PEB STRUCTURES.
Strong &
Durable
Flexible &
Adaptable
Expandable & Quickly Erectable
Low Price &
High Value
Cost & Time
Effective
Tailor-made
Solutions
Eco-friendly & Energy Efficient
CAN WITHSTAND NATURAL DISASTERS
PRIMARY BUILT-UP MEMBER
They consist of:
BUILT-UP “H” SHAPED PRIMARY STRUCTURAL FRAMING MEMBERS COLUMNS RAFTERS
Pinax, an expert Pre Engineered Building Manufacturer Company fabricates the components from high strength grade plates, cut to size and shape as per specifications and used in making built-up sections.Any geometrical frame is possible in this system. Asymmetrical framing systems about the ridgeline and multiple framing systems with unequal width are also possible, but with more engineering time and longer delivery periods. All components are designed for compatibility. These components are fabricated under strict quality control norms as per shop drawings. Functional subsystems include Mezzanine Floors (including Joists and Decking), Crane Runway Beams (to support Crane Systems), Roof Platforms, Catwalks, etc. Aesthetic features include Fascias, Parapets, Canopies and Roof Extensions. These components are transported and assembled at the site as per erection drawings. Pinax's quality check ensures they are one of the leading PEB Manufacturer In India.
APPLICATIONS OF BUILT TO LAST
Industrial Buildings
Metro Stations
Canopies
Warehouses
Secondary Members
Secondary members are composed of Roof Purlins, Wall Girts, Eave Struts and Roofing Sheets. Roof Purlins, Wall Girts & Struts Are Forms Of Z-Purlins, C-Purlins and Hollow Sections. Z-Purlins and C-Purlins are cold formed steel members having a minimum yield strength of 345 MPa with zinc coating (120/180/275 gsm).
Roof Purlins (Z - Purlin)
Roof Purlins (Cold Formed)
Purlins are Z sections with 200 to 300 mm depth & thickness from 1.75 to 2.50 mm as per requirement. They are fixed to the top flanges of the rafters utilizing cleats moulded to the rafters and the purlin web bolted to the cleats. Purlin ends are overlapped to act as continuous beams.
Roof Purlins
Purlins come in 96 x 48 to 172 x 92 mm sizes and thickness from 3.0 to 4.8 mm as per requirement. They are fixed to the top flanges of the rafters by cleats moulded to the rafters and bottom bolted to the cleats and flushed with webs of the rafter resulting in a stronger structure.
Wall Girts (C - Purlin)
Wall Girts (Cold Formed)
Wall Girts shall be Z sections with 200 to 300 mm depth and thickness from 1.75 to 2.50 mm as per requirement. There are two fixation methods:
These girts are fixed to the outer flange of the side wall column by cleats moulded to the side column and the girt web bolted to the cleats. Overlapping connections are provided for continuous beam.
End Wall Girts and Flushed Girts on side walls are flushed to the outer flange of the columns by cleats bolted to the column web and the girt web bolted to the cleats.
Wall Girts (Hot Formed)
Girts are hollow sections with 96 x 48 to 172 x 92 mm sizes and thickness from 3.0 to 4.8 mm as per requirement.
These girts are fixed to the outer flange of the side wall column by cleats moulded to the side column and the girt horizontally bottom bolted to the cleats
End Wall Girts and Flushed Girts on side walls are flushed to the outer flange of the columns by cleats bolted to the column web and the girts horizontally bolted to the bottom of the cleats
Hollow Section (Hot / Cold Rolled)
Hollow sections are Hot Rolled Formed sections with a yield strength of 310 MPa and UTS 450 MPa
Eave Struts
Eave Struts (Cold Formed)
Eave Struts are C & Z sections with 200 to 300 mm depth and thickness from 1.75 to 2.50 mm at the rafter ends. The Struts are fixed to the top flanges of the rafters by cleats moulded to the rafters and the struts web bolted to the cleats. Strut ends are overlapped to act as continuous beams.
Eave Struts (Hot Formed)
Eave Struts are hollow sections with 96 x 48 to 172 x 92 mm sizes and thickness from 3.0 to 4.8 mm. The struts are fixed to the top flanges of the rafters by clips moulded to the rafters and bottom bolted to the cleats and are flushed with web of the rafter resulting in a stronger structure.
Trapozodial Roof Sheet
Roof sheets are cold formed with yield strength of 550 MPa
Roof Sheets
Colour Coated Galvalume Sheets
Roofing Sheets made of metal are used for pre-engineered building solutions. They are 12 m+ in a single length and are self-drilled through fasteners. They are applied for roof slopes as low as 1:20 and are applied as internal lines for double skin roofs and wall constructions without insulation. They can be curved to attain an aesthetic, architectural look.
Base Material – GI, BG, PPGI & PPGL
| Colour Coated Galvalume | Bare Galvalume | Colour Coated Galvanised |
|---|---|---|
| As per IS 513 (AZ 150) | As per IS 513 | As per IS 277 (120 gsm) |
| Thickness - 0.35 to 0.80 mm | Thickness - 0.35 to 0.80 mm | Thickness - 0.35 to 0.80 mm |
COATING SYSTEMS
| RMP | SMP | SDP | PVDF |
|---|---|---|---|
| (Regular Modified) | (Silicon Modified Polyester) | (Super Durable Polyester) | (Polyvinylidene Fluoride Polyester) |
Mount Deck
| Input | Width | Supply | Width Effective | Width Pitch Depth |
|---|---|---|---|---|
| 1220 mm | 1080 mm | 1020 mm | 200 mm | 28 mm |
Available in (1) Colour Coated Galvanised (0.35 to 0.80 mm) (2) Colour Coated Galvalume (0.35 to 0.80 mm)
Accessories
TURBO VENTILATORS
These are velocity driven and centrifugal force generated, creating a low pressure area which draws out stale, damp and hot air through the ventilators and fresh air is automatically replaced. Turbo ventilators are wind driven, energy saving, pollution free and are virtually maintenance free.
LOUVERS
Louvers maintain a regular flow of fresh and natural air in the industrial and storage areas. In combination with Turbo Ventilators, they help in reducing the build-up of dust, vapour and heat inside the building.
FLASHINGS AND TRIMS
Flashings and Trims create harmony and splendour of the pre Engineered Building Structures. These sheet metal closures are designed to protect from weather effects with neat appearances at corners and junctions.
NUT & BOLT / ANCHOR BOLT/ FOUNDATION BOLT
The nuts & bolts provided by us are self-drilling, self-trapping screws & fasteners, which are coated with a combination of Tin-Zinc coating which is mechanically deposited. This coating prevents the accumulation and formation of impurities, moisture, rust, and electrical current, on and around the steel/metal surface.
FRP TRANSLUSENT SHEETS / STRIP LIGHTS
The FRP sheets provided by us are water resistant, non-combustible, and environment friendly. As they are translucent and transparent in nature, they save drastically on the electricity bills.
END EAVE GUTTER
A = 540 mm
B = 200 mm
C = 260 mm
D = 220 mm
E = 25 mm
L = 2440 mm max
Corner Flashing (Wall to Wall)
A = 10 mm
B = 300 mm
= 45
∞ = 90
L = 2440mm
Plain and Profile Ridge
A = 300/400/600 mm
= 140 min. up to 0.50 mm thickness
= 150 min. up to 0.80 mm thickness
For profiled ridge
Length = 1080 mm / 1180 mm
(Effective Length = 1020 mm / 1070mm)
For plain ridge L = 2440
Curved Corner
A = 150/200
B = 300
C = 150/200
R = min 500 mm
W = 1080 mm / 1180 mm
(Effective width = 1020 / 1070 mm)
Polycarbonate Transparent Sheet
2 mm and 3 mm thickness as per profile designed to provide natural lighting in the building
Customised Bend Solutions
R = min 1000 mm
Sheet Length = 4500 mm max
W = 1080 mm / 1180 mm
(Effective Width = 1020 / 1070mm)
Pre-Engineered Green Buildings
According to the world green building council, "a 'green' building is a building in its design, construction or operation, reduces or eliminates negative impacts and creates positive impacts on our climate and natural environment. Green buildings preserve precious natural resources and improve our quality of life."
Pinax Group also specialises in Green Buildings that are designed, built, renovated, operated, or reused in an ecological and resource efficient manner, thus minimising Industrial Shed Construction Cost in India. Green buildings help protect occupant's health and improve employee productivity. Using energy, water and other resources more efficiently, we reduce overall impact on the environment and optimise environmental and economic performance.
